Baterías de litio para plataformas elevadoras (AWP)

Certificaciones

24V 105Ah Aerial Work Platform Battery: 24V 160Ah Aerial Work Platform Battery
Electrical Specifications: Voltaje nominal Nominal Capacity | 25.6V(20~28 V) 105Ah | 25.6V(20~28 V) 160Ah
Stored Energy: 2.68 kWh | 4.09 kWh
Vida útil (ciclos): 3000times Cycles @100%DOD and 6000times @80% DOD
Charge Specifications: Typical Mileage Per Full Charge | 35-48 km (20-30 miles) | /
Continuous Charge: / | 30A
Discharge Specifications: Continuous Discharge | 120A | 120A
Maximum Discharge: 180A(20s) | 180A(20s)
Mechanical Specifications: Dimensions (LxDxH) | 17.6×9.6×10.3 inch (448×244×261 mm) | 20.0×13.8×7.5 inch (508×350×191 mm)
Weight (with counterweight): 53 lbs. (24 kg) | 86 lbs. (39 kg)
Heating: optional | /
Color/material de carcasa: Steel
Clasificación IP: IP65
Temperature Specifications: Temperatura de carga | -4°F~131°F(-20°C ~ 55°C)
Temperatura de descarga: -4°F~131°F(-20°C ~ 55°C)
Storage Temp (1 month): -4°F~113°F (-20°C~45°C)
Storage Temp (1 year): 32°F~95°F ( 0°C ~ 35°C)

Dimensiones y peso en unidades métricas (mm / kg).
